PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Indirect Register 0805H: PRGM Monitor Received B1/E1 Bytes Page
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
REC_E1[7]
REC_E1[6]
REC_E1[5]
REC_E1[4]
REC_E1[3]
REC_E1[2]
REC_E1[1]
REC_E1[0]
REC_B1[7]
REC_B1[6]
REC_B1[5]
REC_B1[4]
REC_B1[3]
REC_B1[2]
REC_B1[1]
REC_B1[0]
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
This indirect register is not valid for PRGM Aux2, Aux3, Aux4.
REC_B1[7:0]:
The Received B1 byte is the content of the B1 byte position in the SONET/SDH frame. Every
time a B1 byte is received, it is copied in this register.
REC_E1[7:0]:
The Received E1 byte is the content of the E1 byte position in the SONET/SDH frame. Every
time a E1 byte is received, it is copied in this register.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
400
