PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0806H: Monitor B1/E1 Bytes Interrupt Status
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
Unused
Unused
R
R
R
R
R
R
R
R
R
R
R
R
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
MON1_B1E1I
X
X
X
X
X
X
X
X
X
X
X
X
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
MON1_B1E1I:
The MON1_B1E1I bit indicates the status of the interrupt generated when a change in the
status of the comparison has been detected on the B1/E1 bytes. The MON1_B1E1I is set
high when the monitor is in the synchronized state and when the status change is detected
on either the B1 or E1 bytes. For example, if a mismatch is detected and the previous
comparison was a match, the MON1_B1E1I bit will be set high. But if a mismatch is detected
and the previous comparison was a mismatch, the MON1_B1E1I bit will keep its previous
value. This bit is independent of MON1_B1E1E, and is cleared after it’s been read.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
389
