PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0809H: PRGM Monitor Synchronization Interrupt Status
Register 0819H: PRGM Aux 2 Monitor Synchronization Interrupt Status
Register 0829H: PRGM Aux 3 Monitor Synchronization Interrupt Status
Register 0839H: PRGM Aux 4 Monitor Synchronization Interrupt Status
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
Unused
Unused
R
R
R
R
R
R
R
R
R
R
R
R
MON[N+12]_SYNCI
MON[N+11]_SYNCI
MON[N+10]_SYNCI
MON[N+9]_SYNCI
MON[N+8]_SYNCI
MON[N+7]_SYNCI
MON[N+6]_SYNCI
MON[N+5]_SYNCI
MON[N+4]_SYNCI
MON[N+3]_SYNCI
MON[N+2]_SYNCI
MON[N+1]_SYNCI
X
X
X
X
X
X
X
X
X
X
X
X
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
MONx_SYNCI:
The Monitor Synchronization Interrupt Status registers indicate synchronization interrupts for
each of the 48 STS-1 paths.
PRGM Monitor Synchronization Interrupt Status register, N = 0.
PRGM Aux2 Monitor Synchronization Interrupt Status register, N = 1.
PRGM Aux3 Monitor Synchronization Interrupt Status register, N = 2.
PRGM Aux4 Monitor Synchronization Interrupt Status register, N = 3.
The Monitor Synchronization Interrupt Status Interrupt (MONx_SYNCI) bit is set high when a
change occures in the monitor’s synchronization status. Whenever a state machine of the x
STS-1 path goes from Synchronized to Out Of Synchronization state or vice-versa, the
MONx_SYNCI is set high. This bit is independent of MONx_SYNCE, and is cleared after it’s
been read.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
392
