PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0763H: RXSDQ FIFO Overflow Port and Interrupt Indication
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
R
R
R
R
R
R
OFL_FIFO[5]
OFL_FIFO[4]
OFL_FIFO[3]
OFL_FIFO[2]
OFL_FIFO[1]
OFL_FIFO[0]
Unused
Bit 8
Bit 7
Bit 6
Unused
Bit 5
Unused
Bit 4
Unused
Bit 3
Unused
Bit 2
Unused
Bit 1
Unused
Bit 0
R
OFLI
OFLI:
This bit is set when there is a FIFO overflow condition. This bit is cleared when read by the
user.
OFL_FIFO[5:0]:
These bits are used to indicate the FIFO identity. This field should contain the same number
as the FIFO_NUMBER [5:0] field in RXSDQ FIFO Indirect Configuration register; otherwise,
an system error should be declared. These bits are valid only when the interrupt bit is logic 1.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
338
