Register 0761H: RXSDQ FIFO Interrupt Enable
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Reserved
EOPE
X
X
X
X
X
X
X
X
X
X
X
X
0
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
R/W
R/W
R/W
R/W
Bit 2
0
Bit 1
SOPE
0
Bit 0
OFLE
0
OFLE:
When this bit is set to 1, FIFO overflows cause the INTB output to be asserted. If this bit is
set to 0, FIFO overflows do not cause INTB to be asserted.
SOPE:
When this bit is set to 1, bad SOP signals cause the INTB output to be asserted. If this bit is
set to 0, bad SOP signals do not cause INTB to be asserted.
EOPE:
When this bit is set to 1, bad EOP signals cause the INTB output to be asserted. If this bit is
set to 0, bad EOP signals do not cause INTB to be asserted.
Reserved:
This bit should be set to logic 0 for proper operation.
