Register 0731H: SARC LOP Pointer Interrupt Enable
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
Unused
Unused
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
PLOPTRE[1]
0
0
0
0
0
0
0
0
0
0
0
0
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
PLOPTRE:
The path loss of pointer interrupt enable (PLOPTRE) bit controls the activation of the interrupt
(INTB) output. When this bit is set to logic 1, the pending interrupt will assert the interrupt
(INTB) output. When this bit is set to logic 0, the pending interrupt will not assert the interrupt
(INTB) output.
