PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0730H: SARC LOP Pointer Status
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
Unused
Unused
R
R
R
R
R
R
R
R
R
R
R
R
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
PLOPTRV
X
X
X
X
X
X
X
X
X
X
X
X
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
PLOPTRV:
The path loss of pointer status (PLOPTRV) bit indicates the current status of the LOP-P
defect for STS-1/STM-0. When PLOPTRCFG register bits are set to 00b, PLOPTRV is
asserted when the pointer is in the LOP state and PLOPTRV is negated when the pointer is
not in the LOP state. When PLOPTRCFG register bits are set to 01b, PLOPTRV is asserted
when the pointer or any of the concatenated pointers is in the LOP state and PLOPTRV is
negated when the pointer and all the concatenation pointers are not in the LOP state. When
PLOPTRCFG register bits are set to 10b, PLOPTRV is asserted when the pointer or any of
the concatenated pointers is in the LOP state or in the AIS state and PLOPTRV is negated
when the pointer and all the concatenation pointers are not in the LOP state or in the AIS
state. When the PLOPTREND register bit is set to one, PLOPPTRV is negated when a AIS-P
defect is detected.
