Register 072A: SARC Path RPAISINS Enable
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
PGROWTH[1]
PGROWTH[0]
PTIMEN
0
0
0
0
0
0
0
0
0
0
0
0
0
0
PTIUEN
PERDIEN
PRDIEN
Bit 8
Bit 7
PPDIEN
Bit 6
PUNEQEN
PPLMEN
Bit 5
Bit 4
PPLUEN
Bit 3
PAISPTREN
PLOPTREN
Reserved
RLAISINSEN
Bit 2
Bit 1
Bit 0
RLAISINSEN, PLOPTREN, PAISPTREN, PPLUEN, PPLMEN, PUNEQEN, PPDIEN, PRDIEN,
PERDIEN, PTIUEN, PTIMEN, PGROWTHEN[1:0]:
The above enable bits allows for the generation of receive path AIS (AIS-P) based on the
following conditions:
- receive LAIS (register 06A4H)
- path loss of pointer defect
- path AIS pointer defect
- path payload label unstable defect
- path payload label mismatch defect
- path unequipped defect
- path payload defect indication defect
- path remote defect indication defect
- path enhanced remote defect indication defect
- path trace identifier unstable defect
- path trace identifier mismatch defect
- path growth defect
When the bit is set high, the corresponding defect indication is ORed with other defect
indications to generate receive AIS-P. When under receive AIS-P, a all ones pattern is
inserted into the receive SPE bytes. When the bit is set low, the corresponding defect
indication does not affect the assertion of AIS-P.
