S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Register 0x047, 0x147, 0x247, 0x347, 0x447, 0x547, 0x647, 0x747:
TPOP Path Trace
Bit
Type
Function
J1[7]
J1[6]
J1[5]
J1[4]
J1[3]
J1[2]
J1[1]
J1[0]
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
0
0
0
0
0
0
0
0
This register allows control over the path trace byte.
J1[7:0]:
The J1[7:0] bits are inserted in the J1 byte position in the transmit stream .
Proprietary and Confidential to PMC-Sierra, Inc., and for its customers’ internal use.
Document No.: PMC- 2010299, Issue 2
197
