S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Register 0x045, 0x145, 0x245, 0x345, 0x445, 0x545, 0x645, 0x745:
TPOP Arbitrary Pointer LSB
Bit
Type
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Function
APTR[7]
APTR[6]
APTR[5]
APTR[4]
APTR[3]
APTR[2]
APTR[1]
APTR[0]
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
0
0
0
0
0
0
0
This register allows an arbitrary pointer to be inserted for diagnostic purposes.
APTR[7:0]:
The APTR[7:0] bits, along with the APTR[9:8] bits in the TPOP Arbitrary Pointer MSB
Register are used to set an arbitrary payload pointer value. The arbitrary pointer value is
inserted in the outgoing stream by writing a logic one to the PLD bit in the TPOP Pointer
Control Register.
If the FTPTR bit in the TPOP Pointer Control register is a logic one, the current APTR[9:0]
value is inserted into the payload pointer bytes (H1 and H2) in the transmit stream.
Configuring the APS interface (setting PROCM high or TXEN high) while the pointer value
is 522, will cause downstream logic to improperly process the SONET stream. In general, a
downstream loss of pointer (LOP) and/or line BIP errors will occur.
A pointer value of 522 can be used if the APS connection is configured (either created or
removed) first with TPOP set to a non-522 value. After the APS link configuration, the
pointer value can be configured to 522.
Proprietary and Confidential to PMC-Sierra, Inc., and for its customers’ internal use.
Document No.: PMC- 2010299, Issue 2
195
