S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Register 0x04E, 0x14E, 0x24E, 0x34E, 0x44E, 0x54E, 0x64E, 0x74E:
TPOP Concatenation LSB
Bit
Type
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Function
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
CONCAT[7]
CONCAT[6]
CONCAT[5]
CONCAT[4]
CONCAT[3]
CONCAT[2]
CONCAT[1]
CONCAT[0]
1
1
1
1
1
1
1
1
Register 0x04F, 0x14F, 0x24F, 0x34F, 0x44F, 0x54F, 0x64F, 0x74F:
TPOP Concatenation MSB
Bit
Type
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Function
Default
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
CONCAT[15]
CONCAT[14]
CONCAT[13]
CONCAT[12]
CONCAT[11]
CONCAT[10]
CONCAT[9]
CONCAT[8]
1
0
0
1
0
0
1
1
These registers allow control over the concatenation indication values transmitted in
SONET/SDH pointers.
CONCAT[15:0]:
The CONCAT[15:0] bits control the value inserted in the some of the H1 and H2 byte
positions when transmitting an STS-3c or STM-1 stream. The value written to
CONCAT[15:8] is inserted in the H1 byte position of STS-1 #5 and STS-1 #9 in the
concatenated stream. The value written to CONCAT[7:0] is inserted in the H2 byte position
of STS-1 #5 and STS-1 #9 in the concatenated stream. The default values represent the
normal concatenation indication (all ones in the pointer bits, zeros in the unused bits, and
NDF indication).
