STANDARD PRODUCT
PM5365 TEMAP
DATASHEET
PMC-1991148
ISSUE 3
HIGH DENSITY VT/TU MAPPER
AND M13 MULTIPLEXER
Address
Register
1584H
1585H
1586H
1587H
TTMP TU #1 in TUG2 #5 of TUG3 #1, Tributary Control
TTMP TU #1 in TUG2 #6 of TUG3 #1, Tributary Control
TTMP TU #1 in TUG2 #7 of TUG3 #1, Tributary Control
Reserved
1588H-
158EH
TTMP TU #2 in TUG2 #1 to TUG#7 of TUG3 #1, Tributary
Control
158FH
Reserved
1590H-
1596H
TTMP TU #3 in TUG2 #1 to TUG#7 of TUG3 #1, Tributary
Control
1597H
Reserved
1598H-
159EH
TTMP TU #4 in TUG2 #1 to TUG#7 of TUG3 #1, Tributary
Control
159FH
Reserved
15A0H-
15BFH
TTMP TUs #1 to 4 in TUG2s #1 to 7 of TUG3 #2, Tributary
Control
15C0H-
15DFH
TTMP TUs #1 to 4 in TUG2s #1 to 7 of TUG3 #3, Tributary
Control
15E0H
15E1H
15E2H
15E3H
15E4H
15E5H
15E6H
15E7H
15E8H
TTMP Reserved
TTMP Time Switch Page Control
TTMP Indirect Time Switch RAM Control and Status
TTMP Indirect Time Switch Tributary Address
TTMP Indirect Time Switch Tributary Data
TTMP Telecom Interface Configuration
TTMP FIFO Depth
TTMP MAP SVRam Capture Address
TTMP MAP SVRam Control Signals and Bistinit Abort
TTMP MAP SVRam Data
15E9H-
15F5H
15F6H-
15FFH
Reserved
