STANDARD PRODUCT
PM5365 TEMAP
DATASHEET
PMC-1991148
ISSUE 3
HIGH DENSITY VT/TU MAPPER
AND M13 MULTIPLEXER
Address
Register
13F8H
13F9H
13FAH
13FBH
13FCH
13FDH
RTOP TU #4 in TUG2 #1 to TUG2 #7, COPSL Interrupt
RTOP TU #4 in TUG2 #1 to TUG2 #7, PSLM Interrupt
RTOP TU #4 in TUG2 #1 to TUG2 #7, PSLU Interrupt
RTOP TU #4 in TUG2 #1 to TUG2 #7, RDI Interrupt
RTOP TU #4 in TUG2 #1 to TUG2 #7, RFI Interrupt
RTOP TU #4 in TUG2 #1 to TUG2 #7, InBand Error
Reporting Configuration
13FEH-
13FFH
RTOP Reserved
1400H
1401H
1402H
1403H
104H
1405H
1406H
1407H
1408H
1409H
140AH
140BH
140CH
140DH
140EH
VTPP Egress, TU #1 in TUG2 #1, Configuration and Status
VTPP Egress, TU #1 in TUG2 #1, Alarm Status
VTPP Egress, TU #1 in TUG2 #2, Configuration and Status
VTPP Egress, TU #1 in TUG2 #2, Alarm Status
VTPP Egress, TU #1 in TUG2 #3, Configuration and Status
VTPP Egress, TU #1 in TUG2 #3, Alarm Status
VTPP Egress, TU #1 in TUG2 #4, Configuration and Status
VTPP Egress, TU #1 in TUG2 #4, Alarm Status
VTPP Egress, TU #1 in TUG2 #5, Configuration and Status
VTPP Egress, TU #1 in TUG2 #5, Alarm Status
VTPP Egress, TU #1 in TUG2 #6, Configuration and Status
VTPP Egress, TU #1 in TUG2 #6, Alarm Status
VTPP Egress, TU #1 in TUG2 #7, Configuration and Status
VTPP Egress, TU #1 in TUG2 #7, Alarm Status
VTPP Egress, TU #1 in TUG2 #1 to TUG2 #7, LOP
Interrupt
140FH
VTPP Egress, TU #1 in TUG2 #1 to TUG2 #7, AIS Interrupt
1410H-
141DH
VTPP Egress, TU #2 in TUG2 #1 to TUG2 #7,
Configuration and Status/Alarm Status
141EH
VTPP Egress, TU #2 in TUG2 #1 to TUG2 #7, LOP
Interrupt
