RTDM Demap State Vector RAM Address
12E6H
12E7H
12E8H
12E9H
12EAH
12EBH
RTDM Demap State Vector RAM Control and Data
RTDM Demap Debug State Vector RAM Data
RTDM Demap State Vector RAM Data
RTDM Demap State Vector RAM Data
RTDM Demap State Vector RAM Data
Reserved
12ECH-
12FFH
1300H
1301H
1302H
1303H
1304H
1305H
1306H
1307H
RTOP TU #1 in TUG2 #1, Configuration
RTOP TU #1 in TUG2 #1, Configuration and Alarm Status
RTOP TU #1 in TUG2 #1, Expected Path Signal Label
RTOP TU #1 in TUG2 #1, Accepted Path Signal Label
RTOP TU #1 in TUG2 #1, BIP-2 Error Count LSB
RTOP TU #1 in TUG2 #1, BIP-2 Error Count MSB
RTOP TU #1 in TUG2 #1, FEBE Error Count LSB
RTOP TU #1 in TUG2 #1, FEBE Error Count MSB
1308H-
130FH
RTOP TU #1 in TUG2 #2, Configuration and Status
Registers
1310H-
1317H
RTOP TU #1 in TUG2 #3, Configuration and Status
Registers
1318H-
131FH
RTOP TU #1 in TUG2 #4, Configuration and Status
Registers
1320H-
1327H
RTOP TU #1 in TUG2 #5, Configuration and Status
Registers
1328H-
132FH
RTOP TU #1 in TUG2 #6, Configuration and Status
Registers
1330H-
1337H
RTOP TU #1 in TUG2 #7, Configuration and Status
Registers
1338H
1339H
133AH
RTOP TU #1 in TUG2 #1 to TUG2 #7, COPSL Interrupt
RTOP TU #1 in TUG2 #1 to TUG2 #7, PSLM Interrupt
RTOP TU #1 in TUG2 #1 to TUG2 #7, PSLU Interrupt
