Philips Semiconductors
Preliminary specification
Stereo audio codec with SPDIF interface
UDA1355H
Table 78 Description of register bits (address 18H)
BIT
SYMBOL
DESCRIPTION
15 to 7
6
−
reserved
SDETR2
Silence detector channel 2 right. If this bit is logic 0 then there is no silence
detection for the right input of channel 2; if this bit is logic 1 then there is silence
detection for the right input of channel 2.
5
4
3
SDETL2
Silence detector channel 2 left. If this bit is logic 0 then there is no silence
detection for the left input of channel 2; if this bit is logic 1 then there is silence
detection for the left input of channel 2.
SDETR1
Silence detector channel 1 right. If this bit is logic 0 then there is no silence
detection for the right input of channel 1; if this bit is logic 1 then there is silence
detection for the right input of channel 1.
SDETL1
Silence detector channel 1 left. If this bit is logic 0 then there is no silence
detection for the left input of channel 1; if this bit is logic 1 then there is silence
detection for the left input of channel 1.
2
1
0
MUTE_STATE_M
Mute status interpolator. If this bit is logic 0 then the interpolator is not muted; if this
bit is logic 1 then the interpolator is muted.
MUTE_STATE_CH2 Mute status channel 2. If this bit is logic 0 then the interpolator channel 2 is not
muted; if this bit is logic 1 then the interpolator channel 2 is muted.
MUTE_STATE_CH1 Mute status channel 1. If this bit is logic 0 then the interpolator channel 1 is not
muted; if this bit is logic 1 then the interpolator channel 1 is muted.
12.3.2 DECIMATOR
Table 79 Register address 28H
BIT
15
14
13
12
11
10
9
8
Symbol
−
−
−
−
−
−
−
−
BIT
7
6
5
4
3
2
1
0
Symbol
−
−
−
−
−
MT_ADC_stat
−
OVERFLOW
Table 80 Description of register bits (address 28H)
BIT
15 to 3
2
SYMBOL
DESCRIPTION
−
reserved
MT_ADC_stat Mute status decimator. If this bit is logic 0 then the decimator is not muted; if this bit is
logic 1 then the decimator is muted.
1
0
−
reserved
OVERFLOW
Overflow decimator. If this bit is logic 0 then there is no overflow in the decimator (digital
level above −1.16 dB.); if this bit is logic 1 then there is an overflow in the decimator.
2003 Apr 10
61
