Philips Semiconductors
Product specification
High speed CAN transceiver
TJA1041A
QUICK REFERENCE DATA
SYMBOL
VCC
PARAMETER
CONDITIONS
operating range
MIN. MAX. UNIT
DC voltage on pin VCC
DC voltage on pin VI/O
DC voltage on pin VBAT
VBAT input current
4.75
2.8
5
5.25
5.25
27
V
VI/O
operating range
V
VBAT
IBAT
operating range
V
VBAT = 12 V
10
30
µA
V
VCANH
VCANL
VSPLIT
Vesd
DC voltage on pin CANH
DC voltage on pin CANL
DC voltage on pin SPLIT
electrostatic discharge voltage
0 < VCC < 5.25 V; no time limit
0 < VCC < 5.25 V; no time limit
0 < VCC < 5.25 V; no time limit
Human Body Model (HBM)
pins CANH, CANL and SPLIT
all other pins
−27
−27
−27
+40
+40
+40
V
V
−6
+6
kV
kV
ns
−4
+4
tPD(TXD-RXD)
Tvj
propagation delay TXD to RXD
virtual junction temperature
VSTB = 0 V
40
255
−40
+150 °C
2004 Feb 20
3
