Philips Semiconductors
Product specification
New In Car Entertainment car radio tuner IC with
Precision Adjacent Channel Suppression (NICE-PACS)
TEA6848H
10 DC CHARACTERISTICS
VDDA(n) = 8.5 V; VDDA5 = 5 V; VDDD = 5 V; Tamb = 25 °C; tested in the circuit of Figs 10 and 11; unless otherwise
specified.
SYMBOL
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
UNIT
Supply voltage
VDDA(n)
VDDA5
VDDD
analog supply voltages 1 to 4 and 6
analog supply voltage 5
8
8.5
9
V
4.75
4.75
5
5
5.25
5.25
V
V
digital supply voltage
Supply current in FM mode
IDDD
digital supply current
Europe/US band
21
26
33
7.3
31
mA
mA
mA
Japan/East Europe band 26.5
5.5
39.5
8.8
IDDA1
analog supply current 1 for FM IF
amplifier
IDDA2
IDDA3
IDDA4
IDDA5
analog supply current 2 for FM RF
analog supply current 3 for tuning PLL
analog supply current 4 for VCO
4.2
3.2
5.2
5.2
4
6.2
4.8
7.8
−
mA
mA
mA
mA
mA
mA
6.5
3.8
7.4
27
analog supply current 5 for on-chip
power supply
Europe/US band
−
Japan/East Europe band
−
−
IDDA6
analog supply current 6 for on-chip
power supply
21.5
32.5
IMIX1OUT1
IMIX1OUT2
bias current of FM mixer output 1
bias current of FM mixer output 2
4.8
4.8
6
6
7.2
7.2
mA
mA
Supply current in AM mode
IDDD
digital supply current
22
27
32
mA
IDDA1
analog supply current 1 for
AM mixer 2
100
120
140
µA
IDDA2
IDDA3
IDDA4
IDDA5
analog supply current 2 for RF
1.4
1.8
5
1.8
2.2
6.5
11
2.2
2.6
8
mA
mA
mA
mA
analog supply current 3 for tuning PLL
analog supply current 4 for VCO
analog supply current 5 for on-chip
power supply
−
−
IDDA6
analog supply current 6 for on-chip
power supply
14
17.5
21
mA
IMIX1OUT1
IMIX1OUT2
bias current of AM mixer 1 output 1
bias current of AM mixer 1 output 2
4.8
4.8
3.6
3.6
6
7.2
7.2
5.4
5.4
mA
mA
mA
mA
6
IAMMIX2OUT1 bias current of AM mixer 2 output 1
IAMMIX2OUT2 bias current of AM mixer 2 output 2
4.5
4.5
On-chip power supply reference current generator: pin IREF
Vo(ref)
Ro
output reference voltage
output resistance
RIREF = 120 kΩ
RIREF = 120 kΩ
RIREF = 120 kΩ
4
4.25
10
−
4.5
−
V
−
kΩ
nA
Io(max)
maximum output current
−100
+100
2004 Nov 12
12
