Philips Semiconductors
Product specification
RF/IF circuit for AM/FM radio
TEA5570
sensitivity at −3 dB limiting.
− − − output voltage (V ) at V = 1 mV; ∆f = ± 22 kHz.
o
i
Fig.7 Sensitivity (V ), output voltage (V ) as a function of temperature behaviour (T ).
amb
i
o
Measured at f = 10,7 MHz in test circuit Fig.10.
i
sensitivity at −3 dB limiting: V = 6,0 V application.
P
− - − - − - sensitivity at −3 dB limiting: V = 4,5 V application.
P
− − − − output voltage (V ) at V = 1 mV; ∆f = ± 22,5 kHz.
o
i
Fig.8 Sensitivity (V ) and output voltage (V ) as a function of supply voltage (V ).
i
o
P
Measured at f = 10,7 MHz in test circuit Fig.10.
i
September 1987
