Philips Semiconductors
Objective specification
Integrated PAL and PAL/NTSC TV
processors
TDA8360; TDA8361; TDA8362
andbook, full pagewidth
MBC211
100%
86%
72%
58%
44%
30%
µs
10 12
22 26
32 36 40 44 48 52 56 60 64
Fig.12 Test signal waveform.
3.2 dB
handbook, full pagewidth
10 dB
13.2 dB
13.2 dB
30 dB
30 dB
SC CC
PC
SC CC
PC
MBC213
BLUE
YELLOW
PC
TEST
CIRCUIT
SPECTRUM
ANALYZER
SC
Σ
ATTENUATOR
gain setting
adjusted for blue
CC
MBC210
Input signal conditions: SC = sound carrier; CC = colour carrier; PC = picture carrier.
All amplitudes with respect to top sync level.
VO at 3.58 or 4.4 MHz
Value at 0.92 or 1.1 MHz = 20 log ------------------------------------------------------------ + 3.6 dB
VO at 0.92 or 1.1 MHz
VO at 3.58 or 4.4 MHz
Value at 2.66 or 3.3 MHz = 20 log ------------------------------------------------------------
VO at 2.66 or 3.3 MHz
Fig.13 Test set-up intermodulation.
30
March 1994
