Philips Semiconductors
Preliminary specification
Video output amplifier
TDA6111Q
FEATURES
GENERAL DESCRIPTION
• High bandwidth and high slew rate
The TDA6111Q is a video output amplifier with 16 MHz
bandwidth. The device is contained in a single in-line 9-pin
medium power (DBS9MPF) package, using high-voltage
DMOS technology, intended to drive the cathode of a
colour CRT.
• Black-current measurement output for Automatic
Black-current Stabilization (ABS)
• Two cathode outputs; one for DC currents, and one for
transient currents
• A feedback output separated from the cathode outputs
• Internal protection against positive appearing
Cathode-Ray Tube (CRT) flashover discharges
• ESD protection
• Simple application with a variety of colour decoders
• Differential input with a designed maximum common
mode input capacitance of 3 pF, a maximum differential
mode input capacitance of 0.5 pF and a differential input
voltage temperature drift of 50 µV/K
• Defined switch-off behaviour.
QUICK REFERENCE DATA
SYMBOL
VDDH
PARAMETER
CONDITIONS
MIN.
TYP.
MAX.
250
UNIT
high level supply voltage
low level supply voltage
quiescent high voltage supply current
quiescent low voltage supply current
input voltage
0
0
−
−
V
V
VDDL
IDDH
IDDL
14
Voc = 0.5VDDH
Voc = 0.5VDDH
7.0
5.0
0
9.0
6.8
−
11.0
8.0
mA
mA
V
VI
VDDL
VDDH
+150
+65
Voc, Vfb
Tstg
output voltage
VDDL
−55
−20
−
V
storage temperature
−
°C
°C
Tamb
operating ambient temperature
−
ORDERING INFORMATION
PACKAGE
TYPE NUMBER
NAME
DESCRIPTION
VERSION
TDA6111Q
DBS9MPF plastic DIL-bent-SIL medium power package with fin; 9 leads
SOT111-1
1995 Feb 07
2
