Philips Semiconductors
Product specification
Dual 16-bit DAC
TDA1541
RATINGS
Limiting values in accordance with the Absolute Maximum System (IEC 134)
Supply voltage ranges
pin 28
VDD
0 to +7
V
pin 26
VDD1
VDD2
0 to −7
V
pin 15
0 to −17
V
Crystal temperature range
Storage temperature range
Operating ambient temperature range
Electrostatic handling(1)
TXTAL −55 to +150
°C
°C
°C
V
Tstg
Tamb
Ves
−55 to +150
−20 to +70
−1000 to +1000
Note
1. Discharging a 250 pF capacitor through a 1 kΩ series resistor.
THERMAL RESISTANCE
From junction to ambient
Rth j-a
=
35
K/W
November 1985
6
