Philips Semiconductors
Product specification
Single-chip 8-bit microcontroller
80C552/83C552
50
40
30
(1)
(2)
I
, I mA
D
DD
20
(3)
(4)
10
0
0
4
8
12
16
f (MHz)
(1) Maximum operating mode; V
= 6V
= 4V
DD
DD
(2) Maximum operating mode; V
(3) Maximum idle mode; V
(4) Maximum idle mode; V
= 6V
= 4V
NOTE:
These values are valid only within the frequency specifications of the device under test.
DD
DD
Figure 10. 16MHz Version Supply Current (I ) as a Function of Frequency at XTAL1 (f
)
DD
OSC
60
(1)
50
(2)
40
30
I
, I mA
D
DD
20
10
0
(3)
(4)
0
4
8
12
16
20
24
f (MHz)
(1) Maximum operating mode; V
(2) Maximum operating mode; V
= 5.5V
= 4.5V
DD
DD
(3) Maximum idle mode; V
(4) Maximum idle mode; V
= 5.5V
= 4.5V
NOTE:
These values are valid only within the frequency specifications of the device under test.
DD
DD
Figure 11. 24MHz Version Supply Current (I ) as a Function of Frequency at XTAL1 (f
)
DD
OSC
19
1998 Aug 13
