LPC2131/32/34/36/38
NXP Semiconductors
Single-chip 16/32-bit microcontrollers
• Built-in baud rate generator.
• Standard modem interface signals included on UART1. (LPC2134/36/38 only)
• The LPC2131/32/34/36/38 transmission FIFO control enables implementation of
software (XON/XOFF) flow control on both UARTs and hardware (CTS/RTS) flow
control on the LPC2134/36/38 UART1 only.
6.10.2 UART features available in LPC213x/01 only
• Fractional baud rate generator enables standard baud rates such as 115200 to be
achieved with any crystal frequency above 2 MHz.
• Auto-bauding.
• Auto-CTS/RTS flow-control fully implemented in hardware (LPC2134/36/38 only).
6.11 I2C-bus serial I/O controller
The LPC2131/32/34/36/38 each contain two I2C-bus controllers.
The I2C-bus is bidirectional, for inter-IC control using only two wires: a Serial Clock Line
(SCL), and a Serial DAta line (SDA). Each device is recognized by a unique address and
can operate as either a receiver-only device (e.g., an LCD driver or a transmitter with the
capability to both receive and send information (such as memory)). Transmitters and/or
receivers can operate in either master or slave mode, depending on whether the chip has
to initiate a data transfer or is only addressed. The I2C-bus is a multi-master bus, it can be
controlled by more than one bus master connected to it.
This I2C-bus implementation supports bit rates up to 400 kbit/s (Fast I2C).
6.11.1 Features
• Standard I2C compliant bus interface.
• Easy to configure as Master, Slave, or Master/Slave.
• Programmable clocks allow versatile rate control.
• Bidirectional data transfer between masters and slaves.
• Multi-master bus (no central master).
• Arbitration between simultaneously transmitting masters without corruption of serial
data on the bus.
• Serial clock synchronization allows devices with different bit rates to communicate via
one serial bus.
• Serial clock synchronization can be used as a handshake mechanism to suspend and
resume serial transfer.
• The I2C-bus may be used for test and diagnostic purposes.
6.12 SPI serial I/O controller
The LPC2131/32/34/36/38 each contain one SPI controller. The SPI is a full duplex serial
interface, designed to be able to handle multiple masters and slaves connected to a given
bus. Only a single master and a single slave can communicate on the interface during a
given data transfer. During a data transfer the master always sends a byte of data to the
slave, and the slave always sends a byte of data to the master.
