NXP Semiconductors
74HC165-Q100; 74HCT165-Q100
8-bit parallel-in/serial out shift register
DHVQFN16: plastic dual in-line compatible thermal enhanced very thin quad flat package; no leads;
SOT763-1
16 terminals; body 2.5 x 3.5 x 0.85 mm
D
B
A
A
A1
E
c
terminal 1
index area
detail X
terminal 1
index area
e
2
L
e1
b
7
v
M
C A B
w
M
C
y1 C
C
y
1
Eh
16
8
e
9
15
Dh
10
X
2.5
scale
5 mm
0
DIMENSIONS (mm are the original dimensions)
UNIT
mm
A
(1)
max.
1
A1
0.05
0.00
b
0.30
0.18
c
0.2
D
(1)
3.6
3.4
Dh
2.15
1.85
E
(1)
2.6
2.4
Eh
1.15
0.85
e
0.5
e1
2.5
L
0.5
0.3
v
0.1
w
0.05
y
0.05
y1
0.1
Note
1. Plastic or metal protrusions of 0.075 mm maximum per side are not included.
OUTLINE
VERSION
SOT763-1
REFERENCES
IEC
---
JEDEC
MO-241
JEITA
---
EUROPEAN
PROJECTION
ISSUE DATE
02-10-17
03-01-27
Fig 15. Package outline SOT763-1 (DHVQFN16)
74HC_HCT165_Q100
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2012. All rights reserved.
Product data sheet
Rev. 1 — 17 July 2012
17 of 21
