“ZNR” Transient/Surge Absorbers (Type D)
“ZNR”
Transient/Surge Absorbers
D
Series:
V
Type:
“ZNR” Transient/Surge Absorber, Series V, Type D
features large surge current and energy handling
capability for absorbing transient overvoltage in a
compact size.
Large withstanding surge current capability in compact
sizes
Large “Energy Handling Capability” absorbing transient
overvoltages in compact sizes
Wide range of varistor voltages
The standard products shown below have received
UL, CSA and VDE standards
Varistor voltage 82-150V : UL, VDE
Varistor voltage 200V over : UL, CSA, VDE
(cf. Application Notes for UL/CSA, VDE recognized
parts on page 322 to 323)
●RoHS compliant
UL1414, UL1449
CSA C22.2 No.1 Class 2221 01
VDE CECC42000, CECC42200, CECC42201, IEC61051
“Type Designation(UL)”, “Part Number(CSA)” ,“Style
Ref. (VDE)”
Are not registered by product Part No..
(Refer to page 322, for the details)
Features
Recommended Applications
Transistor, diode, IC, thyristor or triac semiconductor
protection
Surge protection in consumer electronic equipment
Surge protection in communication, measuring or
controller electronics
Surge protection in electronic home appliances, gas or
petroleum appliances
Relay or electromagnetic valve surge absorption
Handling Precautions
Please see Pages 335 to 337
Related Standards
Minimum Quantity / Packing Unit
Please see Page 360
Explanation of Part Numbers (Bulk)
1
2
3
4
5
6
7
8
9
10
11
12
E
R
Product Code
Z
V
Series
D
Design No.
Element Size
φ
10 mm
φ
5 mm
10
φ
14 mm
φ
7 mm
14
φ
20 mm
φ
10 mm
20
Lead Configuration
D Straight Lead
V Crimped Lead
½
½
Excluding
φ20.
½
Only the lead cut
05
07
09
Norminal Varistor Voltage
The first two digits are significant
figures and the third one denotes
the number of zeros following.
Explanation of Part Numbers (Taping)
1
2
3
4
5
6
7
8
9
10
11
12
E
R
Product Code
Z
V
Series
Element Size
φ
5 mm
5
φ
7 mm
7
φ
10 mm
9
φ
10 mm
A
φ
14 mm
E
D
Design No.
Lead Configuration
D
Straight Lead
Crimped Lead
V
Nominal Varistor Voltage
The first two digits are significant
figures and the third one denotes
the number of zeros following.
Taping / Packaging
A to D Radial Taping (P
0
=12.7 mm)
E to H Radial Taping (P
0
=15.0 mm)
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
00 Sep. 2010
– 300 –
