PFS122
8bit MTP MCU with 12-bit R-Type ADC
pcadd
a
Next program counter is current program counter plus ACC.
Example: pcadd a;
Result: pc ← pc + a
Affected flags: 『N』Z 『N』C 『N』AC 『N』OV
Application Example:
------------------------------------------------------------------------------------------------------------------------
…
mov
pcadd
goto
goto
goto
goto
…
a, 0x02 ;
a ;
// PC <- PC+2
// jump here
err1 ;
correct ;
err2 ;
err3 ;
correct:
// jump here
…
------------------------------------------------------------------------------------------------------------------------
Enable global interrupt enable
engint
Example: engint;
Result: Interrupt request can be sent to CPU
Affected flags: 『N』Z 『N』C 『N』AC 『N』OV
Disable global interrupt enable
disgint
stopsys
stopexe
Example: disgint ;
Result: Interrupt request is blocked from CPU
Affected flags: 『N』Z 『N』C 『N』AC 『N』OV
System halt.
Example: stopsys;
Result: Stop the system clocks and halt the system
Affected flags: 『N』Z 『N』C 『N』AC 『N』OV
CPU halt. The oscillator module is still active to output clock, however, system clock is disabled
to save power.
Example: stopexe;
Result: Stop the system clocks and keep oscillator modules active.
Affected flags: 『N』Z 『N』C 『N』AC 『N』OV
Reset the whole chip, its operation will be same as hardware reset.
Example: reset;
reset
Result: Reset the whole chip.
Affected flags: 『N』Z 『N』C 『N』AC 『N』OV
7.8. Summary of Instructions Execution Cycle
goto, call, idxm, pcadd, ret, reti
2T
2T
1T
1T
Condition is fulfilled.
ceqsn, cneqsn,t0sn, t1sn, dzsn, izsn
Condition is not fulfilled.
Others
©Copyright 2020, PADAUK Technology Co. Ltd
Page 85 of 93
PDK-DS-PFS122-EN_V000-May 28, 2020
