PFS122
8bit MTP MCU with 12-bit R-Type ADC
7.5. Bit Operation Instructions
set0 IO.n
set1 IO.n
swapc IO.n
Set bit n of IO port to low
Example: set0 pa.5 ;
Result: set bit 5 of port A to low
Affected flags: 『N』Z 『N』C 『N』AC 『N』OV
Set bit n of IO port to high
Example: set1 pb.5 ;
Result: set bit 5 of port B to high
Affected flags: 『N』Z 『N』C 『N』AC 『N』OV
Swap the nth bit of IO port with carry bit
Example: swapc
IO.0;
Result: C ← IO.0 , IO.0 ← C
When IO.0 is a port to output pin, carry C will be sent to IO.0;
When IO.0 is a port from input pin, IO.0 will be sent to carry C;
Affected flags: 『N』Z 『Y』C 『N』AC 『N』OV
Application Example1 (serial output) :
------------------------------------------------------------------------------------------------------------------------
...
set1
...
pac.0 ;
// set PA.0 as output
set0
swapc
set1
swapc
...
flag.1 ;
pa.0 ;
// C=0
// move C to PA.0 (bit operation), PA.0=0
// C=1
flag.1 ;
pa.0 ;
// move C to PA.0 (bit operation), PA.0=1
------------------------------------------------------------------------------------------------------------------------
Application Example2 (serial input) :
------------------------------------------------------------------------------------------------------------------------
...
set0
...
pac.0 ;
// set PA.0 as input
swapc
src
pa.0 ;
a ;
// read PA.0 to C (bit operation)
// shift C to bit 7 of ACC
swapc
src
pa.0 ;
a ;
// read PA.0 to C (bit operation)
// shift new C to bit 7, old C
...
------------------------------------------------------------------------------------------------------------------------
Set bit n of memory to low
set0 M.n
set1 M.n
Example: set0 MEM.5 ;
Result: set bit 5 of MEM to low
Affected flags: 『N』Z 『N』C 『N』AC 『N』OV
Set bit n of memory to high
Example: set1 MEM.5 ;
Result: set bit 5 of MEM to high
Affected flags: 『N』Z 『N』C 『N』AC 『N』OV
