MC10H166
5−Bit Magnitude
Comparator
Description
The MC10H166 is a 5Bit Magnitude Comparator and is a
functional/ pinout duplication of the standard MECL 10Kpart with
100% improvement in propagation delay and no increase in
powersupply current.
The MC10H166 is a highspeed expandable 5bit comparator for
comparing the magnitude of two binary words. Two outputs are
provided: A < B and A > B. The A = B function can be obtained by
wireORing these outputs (a low level indicates A = B) or by
wireNORing the outputs (a high level indicates A = B). A high level
on the enable function forces both outputs low.
http://onsemi.com
MARKING DIAGRAMS*
16
MC10H166L
AWLYYWW
1
Features
CDIP16
L SUFFIX
CASE 620A
Propagation Delay, DatatoOutput, 2.0 ns Typical
Power Dissipation 440 mW Typical
Improved Noise Margin 150 mV (Over Operating Voltage and
Temperature Range)
Voltage Compensated
16
1
MECL 10K Compatible
MC10H166P
AWLYYWWG
16
PbFree Packages are Available*
1
TRUTH TABLE
PDIP16
P SUFFIX
CASE 648
Inputs
Outputs
E
H
L
A
B
X
A < B A > B
X
L
L
L
L
WORD A = WORD B
WORD A > WORD B
WORD A < WORD B
1 20
L
L
H
L
L
H
20
DIP
10H166G
1
PIN ASSIGNMENT
AWLYYWW
PLLC20
FN SUFFIX
CASE 775
V
V
E
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
CC1
CC2
A>B
A<B
B0
B2
A2
A3
A
= Assembly Location
= Year
A0
WL, L = Wafer Lot
YY, Y
WW, W = Work Week
G
A1
B3
B4
A4
= PbFree Package
B1
V
EE
Pin assignment is for DualinLine Package.
For PLCC pin assignment, see the Pin Conversion Tables on page 18
of the ON Semiconductor MECL Data Book (DL122/D).
*For additional marking information, refer to
Application Note AND8002/D.
*For additional information on our PbFree strategy and soldering details, please
download the ON Semiconductor Soldering and Mounting Techniques
Reference Manual, SOLDERRM/D.
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 5 of this data sheet.
©
Semiconductor Components Industries, LLC, 2006
1
Publication Order Number:
March, 2006 Rev. 7
MC10H166/D
