Absolute Maximum Ratings
Stresses exceeding the absolute maximum ratings may damage the device. The device may not function or be operable
above the recommended operating conditions and stressing the parts to these levels is not recommended. In addition,
extended exposure to stresses above the recommended operating conditions may affect device reliability. The absolute
maximum ratings are stress ratings only. Functional operation under any of these conditions is NOT implied.
Performance and reliability are guaranteed only if operating conditions are not exceeded.
Symbol
VCC
VIN
Parameter
Min.
0
Max.
6
Unit
V
Supply Voltage
Input Voltage Range
Junction Temperature
Storage Temperature
-VS-0.5
+VS+0.5
+150
+150
+300
331
V
TJ
°C
TSTG
TL
-65
°C
Lead Soldering, 10 Seconds
Thermal Resistance(1)
°C
°C/W
ΘJA
Human Body Model,
JESD22-A114
5
2
ESD
Electrostatic Discharge Capability
kV
Charged Device Model,
JESD22-C101
Note:
Package thermal resistance JEDEC standard, multi-layer test boards, still air.
1.
Recommended Operating Conditions
The Recommended Operating Conditions table defines the conditions for actual device operation. Recommended
operating conditions are specified to ensure optimal performance to the datasheet specifications. Fairchild does not
recommend exceeding them or designing to Absolute Maximum Ratings.
Symbol
Parameter
Min.
2.30
-40
Max.
5.25
Unit
V
+VS
Supply Voltage
Operating Temperature Range
TA
+125
°C
© 2008 Fairchild Semiconductor Corporation
FAN4931 • Rev. 1.0.2
www.fairchildsemi.com
3
