CM2020-00TR
Specifications
ABSOLUTE MAXIMUM RATINGS
PARAMETER
V
CC5V
, V
CCLV
DC Voltage at any Channel Input
Storage Temperature Range
RATING
6.0
6.0
-65 to +150
UNITS
V
V
°
C
STANDARD (RECOMMENDED) OPERATING CONDITIONS
SYMBOL
5V_SUPPLY
LV_SUPPLY
PARAMETER
Operating Supply Voltage
Bias Supply Voltage
Operating Temperature Range
MIN
GND
1
-40
TYP
5
3.3
MAX
5.5
5.5
85
UNITS
V
V
°
C
ELECTRICAL OPERATING CHARACTERISTICS
(SEE NOTE 1)
SYMBOL
I
CC5V
I
CCLV
V
DROP
I
SC
I
OFF
I
BACKDRIVE
PARAMETER
Operating Supply Current
Bias Supply Current
5V_OUT Overcurrent Output
Drop
5V_OUT Short Circuit Current
Limit
OFF state leakage current, level
shifting NFET
Current conducted from output
pins to V_SUPPLY rails when
powered down
CONDITIONS
5V_SUPPLY = 5.0V
LV_SUPPLY = 3.3V
5V_SUPPLY= 5.0V,
I
OUT
=55mA
5V_SUPPLY= 5.0V,
5V_OUT = GND
LV_SUPPLY 0V
5V_SUPPLY V
CH_OUT
;
Signal pins: TMDS_D[2:0]+/-,
TMDS_CK+/-, CE_REMOTE_OUT,
DDC_DAT_OUT, DDC_CLK_OUT,
HOTPLUG_DET_OUT, 5V_OUT
Only
CE-REMOTE_IN = LV_SUPPLY <
CE_REMOTE_OUT
90
MIN
TYP
110
1
65
135
0.1
0.1
MAX
130
5
100
175
5
5
UNITS
µA
µA
mV
mA
µA
µA
I
BACKDRIVE,
CEC
Current through
CE-REMOTE_OUT when
powered down
0.1
1
µA
