Part Names
Sensor Heads (Reflective)
ZX-LD40
Amplifier Units
ZX-LDA11-N
ZX-LDA41-N
ZX-LD100
Controls
ZX-LD300
ZX-LD40L
Display area
ZX-LD100L
ZX-LD300L
ZX-LD30V*
Display area
Input cable (with connector)
ZX-LD30VL*
Receiver
(Optical filter)
Output cable
Connector
(Cover opens and closes.)
Output cable (with connector)
*The dimensions for these models are slightly different. Refer to page 23 for details.
Sensor Heads (Through-beam)
ZX-LT001
Calculating Unit
ZX-CAL2
ZX-LT005
ZX-LT010
ZX-LT030
Display area
Emitter
Laser ON
indicator (green)
Light emitter
Lit when light is
emitted.
Emitter side
sensor head
connector
Emitter
Connector
Receiver side
(Optical filter)
Receiver side sensor
head connector
Receiver
ZX Series (ZX-L-N) Smart Sensors (Laser Type)
15
