I/O Circuit Diagrams
PNP Amplifier Unit: ZX-LDA41-N
NPN Amplifier Unit: ZX-LDA11-N
Brown: 12 to 24 VDC
Brown: 12 to 24 VDC
White: HIGH
output
White: HIGH output
Green: PASS output
Gray: LOW output
Green: PASS output
Gray: LOW output
12 to
24 VDC
12 to
24 VDC
Blue: GND (0V)
Blue: GND (0V)
Pink: Laser OFF input
Purple: Timing input
Pink: Laser OFF input
Purple: Timing input
Orange: Zero reset input
Red: Reset input
Orange: Zero reset input
Red: Reset input
Current output
4 to 20 mA
Current/voltage
Black: Linear output
switch
Current output
4 to 20 mA
Voltage output
4V
Black: Linear output
Shield: Linear GND
Current output: 300 Ω max.
Voltage output: 10 kΩ min.
Current/voltage
switch
Current output: 300 Ω max.
Voltage output: 10 kΩ min.
Voltage output
4V
Shield: Linear GND
100 Ω
100 Ω
Connections: Amplifier Unit
Brown:
12 to 24 VDC
Blue:
GND (0V)
White:
HIGH output
Green:
PASS output
Gray:
LOW output
Black:
Linear output
Shield:
Linear output GND
Pink:
Laser OFF input
Orange:
Zero reset input
Purple:
Timing input
Red:
Reset input
Note 1. Use a separate stabilized power supply for the Amplifier Unit,
particularly when high resolution is required.
2. Wire the Unit correctly. Incorrect wiring may result in damage to
the Unit. (Do not allow wiring, particularly the linear output, to
come into contact with other lines.)
3. Use the 0-V line (blue) for the power supply and use the shield
wire (linear output ground) together with the linear output (black
line) for linear output. Each of these grounds must be used for
the designed purpose. When not using the linear output, con-
nect the linear ground (shield) to the 0-V ground.
