E2E
E2E-X@E@/F@ DC 3-Wire Models
Size
M8
M12
M18
M30
Shielded
Shielded
E2E
-X1R5E@/F@
1.5 mm 10%
0 to 1.2 mm
Unshielded
Shielded
E2E
-X2E@/F@
Unshielded
Shielded
E2E
-X5E@/F@
Unshielded
Shielded
Unshielded
E2E
E2E
E2E
E2E-X10E@/
F@
E2E
Item
Model
-X2ME@/F@
2 mm 10%
0 to 1.6 mm
-X5ME@/F@
5 mm 10%
0 to 4 mm
-X10ME@/F@
10 mm 10%
0 to 8 mm
-X18ME@/F@
18 mm 10%
0 to 14 mm
Sensing distance
Set distance
Differential travel
Detectable object
10% max. of sensing distance
Ferrous metal (The sensing distance decreases with non-ferrous metal. Refer to Engineering Data on pages 18 and 19.)
Standard sensing
object
Iron,
Iron,
Iron,
Iron,
Iron, 12 × 12 × 1 mm
0.8 kHz 1.5 kHz
Iron, 30 × 30 × 1 mm
0.2 kHz 0.4 kHz
8 × 8 × 1 mm
15 ×15 × 1 mm 18 × 18 × 1 mm
54 × 54 × 1 mm
Response frequency
*1
2 kHz
0.4 kHz 0.6 kHz
0.1 kHz
Power supply voltage
(operating voltage
range) *2
12 to 24 VDC (10 to 40 VDC), ripple (p-p): 10% max.
Current consumption 13 mA max.
Load
200 mA max.
current *2
Control
output
Residual
2 V max. (Load current: 200 mA, Cable length: 2 m)
voltage
Indicators
Operation indicator (red)
Operation mode
(with sensing object
approaching)
E1/F1 Models: NO
E2/F2 Models: NC
Refer to the timing charts under I/O Circuit Diagrams on page 21 for details.
Protection circuits
Load short-circuit protection, Surge suppressor, Reverse polarity protection
Ambient
temperature range *2
Operating/Storage: −40 to 85°C (with no icing or condensation)
Ambient humidity
range
Operating/Storage: 35% to 95% (with no condensation)
Temperature
influence
15% max. of sensing distance at 23°C in the temperature range of −40 to 85°C
10% max. of sensing distance at 23°C in the temperature range of −25 to 70°C
Voltage influence
1% max. of sensing distance at rated voltage in the rated voltage 15% range
Insulation resistance 50 MΩ min. (at 500 VDC) between current-carrying parts and case
Dielectric strength
Vibration resistance
1,000 VAC, 50/60 Hz for 1 minute between current carry parts and case
Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions
Destruction: 500 m/s2
Shock resistance
10 times each in X, Y, and
Z directions
Destruction: 1,000 m/s2 10 times each in X, Y, and Z directions
Pre-wired Models : IEC 60529 IP67, in-house standards: oil-resistant
Connector Models : IEC 60529 IP67
Degree of protection
Connection method
Pre-wired Models (Standard cable length: 2 m) and Connector Models
Pre-
wired
Approx. 65 g
Approx. 15 g
Approx. 75 g
Approx. 150 g
Approx. 40 g
Approx. 195 g
Approx. 90 g
Models
Weight
Connec-
tor
Models
Approx. 25 g
Case
Stainless steel (SUS303)
PBT
Nickel-plated brass
Sensing
surface
Materials
Clamp-
ing nuts
Nickel-plated brass
Toothed
washer
Zinc-plated iron
Accessories
Instruction manual
*1. The response frequency is an average value. Measurement conditions are as follows: standard sensing object, a distance of twice the standard sensing object, and
a set distance of half the sensing distance.
*2. When using an M8 Model at an ambient temperature between 70 and 85°C, supply 10 to 30 VDC to the Sensor and make sure that the Sensor has a control output
of 100 mA maximum.
16
