E2E
Ratings and Specifications
E2E-X@D@ DC 2-Wire Models
Size
Shielded
Item
Shielded
2 mm
±10%
0 to 1.6 mm
M8
Unshielded
E2E-X4MD@
4 mm
±10%
0 to 3.2 mm
Shielded
E2E-X3D@
3 mm
±10%
0 to 2.4 mm
M12
Unshielded
E2E-X8MD@
8 mm
±10%
0 to 6.4 mm
Shielded
E2E-X7D@
7 mm
±10%
0 to 5.6 mm
M18
Unshielded
E2E-X14MD@
14 mm
±10%
0 to 11.2 mm
Shielded
E2E-X10D@
10 mm
±10%
0 to 8 mm
M30
Unshielded
E2E-X20MD@
20 mm
±10%
0 to 16 mm
Model E2E-X2D@
Sensing distance
Set distance
*1
Differential travel
Detectable object
Standard sensing
object
Response frequency
*2
Power supply voltage
(operating voltage
range)
Leakage current
Load
current
Residual
voltage
*3
15% max. of sensing distance
10% max. of sensing distance
Ferrous metal (The sensing distance decreases with non-ferrous metal. Refer to
Engineering Data
on pages 18 and 19.
Iron,
8
×
8
×
1 mm
1.5 kHz
Iron,
Iron,
Iron,
Iron,
Iron, 30
×
30
×
1 mm
20
×
20
×
1 mm 12
×
12
×
1 mm 30
×
30
×
1 mm 18
×
18
×
1 mm
1 kHz
0.8 kHz
0.5 kHz
0.4 kHz
Iron,
54
×
54
×
1 mm
0.1 kHz
12 to 24 VDC (10 to 30 VDC), ripple (p-p): 10% max.
0.8 mA max.
3 to 100 mA, Diagnostic output: 50 mA for -D1(5)S Models
3 V max. (Load current: 100 mA, Cable length: 2 m, M1J-T Models only: 5 V max.)
D1 Models: Operation indicator (red) and setting indicator (green)
D2 Models: Operation indicator (red)
D1 Models: NO
D2 Models: NC
0.3 to 1 s
Surge suppressor, Load short-circuit protection (for control and diagnostic output)
Operating:
−25
to 70°C, Storage:
−40
to 85°C (with no icing or condensation)
Operating/storage: 35% to 95% (with no condensation)
±15%
max. of sensing distance
at 23°C in the temperature range
of
−25
to 70°C
±10%
max. of sensing distance at 23°C in the temperature range of
−25
to 70°C
Refer to the timing charts under
I/O Circuit Diagrams
on page 21 for details.
Control
output
Indicators
Operation mode
(with sensing object
approaching)
Diagnostic output
delay
Protection circuits
Ambient
temperature range
Ambient
humidity range
Temperature
influence
Voltage influence
Insulation resistance
Dielectric strength
Vibration resistance
Shock resistance
Degree of protection
Connection method
Pre-wired
Models
Weight
Pre-wired
(pack-
Connector
ed
Models
state)
Connector
Models
Case
Sensing sur-
face
±1%
max. of sensing distance at rated voltage in the rated voltage
±15%
range
50 MΩ min. (at 500 VDC) between current-carrying parts and case
1000 VAC, 50/60 Hz for 1 minute between current carry parts and case
Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions
Destruction: 500 m/s
2
10 times each in X, Y, and
Z directions
Destruction: 1,000 m/s
2
10 times each in X, Y, and Z directions
Pre-wired Models: IEC 60529 IP67, in-house standards: oil-resistant
Connector Models: IEC 60529 IP67
Pre-wired Models (Standard cable length: 2 m), Connector Models, or Pre-wired Connector Models (Standard cable length: 0.3 m)
Approx. 60 g
---
Approx. 15 g
Stainless steel (SUS303)
PBT
Nickel-plated brass
Zinc-plated iron
Instruction manual
Approx. 70 g
Approx. 40 g
Approx. 25 g
Nickel-plated brass
Approx. 130 g
Approx. 70 g
Approx. 40 g
Approx. 175 g
Approx. 110 g
Approx. 90 g
Materi-
Clamping
als
nuts
Toothed
washer
Accessories
*1. Use the E2E within the range in which the setting indicator (green LED) is ON (except D2 Models).
*2. The response frequency is an average value.
Measurement conditions are as follows: standard sensing object, a distance of twice the standard sensing object, and a set distance of half the sensing distance.
*3. The residual voltage of each M1J-T Model is 5 V. When connecting to a device, make sure that the device can withstand the residual voltage. (Refer to page 28 for
details.)
13
