D4B-@N
Engineering Data
(Ambient temperature: 5 to 30°C, ambient humidity: 40 to 70%)
Electrical Durability (Snap-action)
(cosφ = 1)
1,000
(cosφ = 0.4)
1,000
Operating frequencies:
30 times/min., cosφ = 0.4
Operating frequencies:
30 times/min., cosφ = 1
500
300
500
300
125 VAC
250 VAC
480 VAC
250 VAC
100
50
100
50
30
10
30
10
500 VAC
Switching current (A)
Switching current (A)
Structure and Nomenclature
Structure
Head
Can be connected in any of four directions (except for
Roller Plunger Models, which can be connected at either
of 2 directions that differ by 90°)
The roller lever switch employs a
system which allows
Roller
selection of operation on only one
side (left or right)
Nylon rollers used for superior resistance to wear.
or both sides without the use of
any tools.
Lever (Form Lock Structure)
The lever has an operating position indication plate
and grooves that mate every 90° to prevent slipping
between the rotary axis and lever.
Seal Ring
Sealing properties improved by using a X ring and
bearing-free structure.
The operating position indicator plate
Built-in Switch
Direct opening mechanism used for NC contact to
separate contact for faults, such as contact welding.
The heights of the NC and NO terminals are different
to enable easier wiring.
Conduit Opening
Models are available with a wide range of conduits.
Size
Box
1-conduit model 2-conduit model
Yes
Yes
Yes
Pg13.5
G1/2
Yes
Yes
Yes
Cover
1/2-14NPT
Ground Screw
Ground screws are provided on all
models for increased safety.
Note: NBR is used for rubber parts.
7
