CP1E-E@@D@-@ CP1E-N@@D@-@/NA20D@-@
●Analog I/O Units
Model
CP1W-MAD11
Item
Voltage I/O
Current I/O
Number of inputs
2 inputs (2 words allocated)
0 to 5 VDC, 1 to 5 VDC,
0 to 10 VDC, or −10 to 10 VDC
Input signal range
0 to 20 mA or 4 to 20 mA
Max. rated input
External input impedance
Resolution
15 V
30 mA
1 MΩ min.
Approx. 250 Ω
1/6000 (full scale)
0.3% full scale
0.6% full scale
Analog Input
Section
25°C
0.4% full scale
0.8% full scale
Overall accuracy
0 to 55°C
16-bit binary (4-digit hexadecimal)
A/D conversion data
Averaging function
Full scale for −10 to 10 V: F448 to 0BB8 hex
Full scale for other ranges: 0000 to 1770 hex
Supported (Settable for individual inputs via DIP switch)
Supported
Open-circuit detection function
Number of outputs
1 output (1 word allocated)
1 to 5 VDC, 0 to 10 VDC, or
−10 to 10 VDC,
Output signal range
0 to 20 mA or 4 to 20 mA
600 Ω max.
Allowable external output load resistance
External output impedance
Resolution
1 kΩ min.
0.5 Ω max.
Analog Output
Section
1/6000 (full scale)
0.4% full scale
0.8% full scale
25°C
Overall accuracy
0 to 55°C
16-bit binary (4-digit hexadecimal)
Set data (D/A conversion)
Full scale for −10 to 10 V: F448 to 0BB8 hex
Full scale for other ranges: 0000 to 1770 hex
Conversion time
2 ms/point (6 ms/all points)
Photocoupler isolation between analog I/O terminals and internal circuits.
No isolation between analog I/O signals.
Isolation method
Current consumption
5 VDC: 83 mA max., 24 VDC: 110 mA max.
●Temperature Sensors Units
Item
CP1W-TS001
Thermocouples
CP1W-TS002
CP1W-TS101
CP1W-TS102
Platinum resistance thermometer
Temperature sensors
Switchable between K and J, but same type must be used for Switchable between Pt100 and JPt100, but same type must
all inputs.
be used for all inputs.
Number of inputs
2
2
4
4
2
2
4
4
Allocated input words
(The larger of 0.5% of converted value or 2°C) 1 digit
max. *
(The larger of 0.5% of converted value or 1°C) 1 digit
max.
Accuracy
Conversion time
250 ms for 2 or 4 input points
Converted temperature data
Isolation
16-bit binary data (4-digit hexadecimal)
Photocouplers between all temperature input signals
5 VDC: 40 mA max., 24 VDC: 59 mA max.
Current consumption
5 VDC: 54 mA max., 24 VDC: 73 mA max.
* Accuracy for a K-type sensor at -100°C or less is ±4°C ±1 digit max.
The rotary switch is used to set the temperature range.
CP1W-TS001/TS002
Setting
CP1W-TS101/TS102
Input type
Range (°C)
−200 to 1,300
0.0 to 500.0
Range (°F)
−300 to 2,300
0.0 to 900.0
Input type
Pt100
Range (°C)
−200.0 to 650.0
−200.0 to 650.0
Range (°F)
−300.0 to 1,200.0
−300.0 to 1,200.0
0
K
1
JPt100
---
2
−100 to 850
−100 to 1,500
0.0 to 750.0
J
3
0.0 to 400.0
---
Cannot be set.
4 to F
---
Cannot be set.
---
●CompoBus/S I/O Link Unit
Model number
CP1W-SRT21
Master/slave
CompoBus/S Slave
Number of I/O points
8 input points, 8 output points
1 input word, 1 output word
Set using the DIP switch
Number of words allocated in CPU
Unit I/O memory
Node number setting
(Set before turning on the CPU Unit’s power supply.)
30
