LPC546xx
NXP Semiconductors
32-bit ARM Cortex-M4 microcontroller
Table 4.
Symbol
Pin description …continued
Description
[2]
PIO0_26
H10 M13 110 56
PU I/O PIO0_26 — General-purpose digital input/output pin.
I/O FC2_RXD_SDA_MOSI — Flexcomm 2: USART receiver, I2C
data I/O, SPI master-out/slave-in data.
O
I
CLKOUT — Output of the CLKOUT function.
CT3_CAP2 — Capture input 2 to Timer 3.
SCT0_OUT5 — SCTimer/PWM output 5.
O
O
PDM0_CLK — Clock for PDM interface 0, for digital
microphone.
O
I
SPIFI_CLK — Clock output for the SPI Flash Interface.
USB0_IDVALUE — Indicates to the transceiver whether
connected as an A-device (USB0_ID LOW) or B-device
(USB0_ID HIGH).
[2]
PIO0_27
H7 L9
87
42
PU I/O PIO0_27 — General-purpose digital input/output pin.
I/O FC2_TXD_SCL_MISO — Flexcomm 2: USART transmitter,
I2C clock, SPI master-in/slave-out data.
R — Reserved.
O
O
I
CT3_MAT2 — Match output 2 from Timer 3.
SCT0_OUT6 — SCTimer/PWM output 6.
PDM0_DATA — Data for PDM interface 0 (digital
microphone).
I/O SPIFI_IO3 — Data bit 3 for the SPI Flash Interface.
PU I/O PIO0_28 — General-purpose digital input/output pin.
I/O FC0_SCK — Flexcomm 0: USART or SPI clock.
R — Reserved.
[2]
PIO0_28
J7
M9 91
44
I
CT2_CAP3 — Capture 3 input to Timer 2.
SCT0_OUT7 — SCTimer/PWM output 7.
TRACEDATA[3] — Trace data bit 3.
O
O
I/O SPIFI_IO2 — Data bit 2 for the SPI Flash Interface.
I
USB0_OVERCURRENTN — USB0 bus overcurrent indicator
(active low).
[2]
PIO0_29
B7 B13 167 82
PU I/O PIO0_29 — General-purpose digital input/output pin.
Remark: In ISP mode, this pin is set to the Flexcomm 0
USART RXD function.
I/O FC0_RXD_SDA_MOSI — Flexcomm 0: USART receiver, I2C
data I/O, SPI master-out/slave-in data.
R — Reserved.
O
O
O
CT2_MAT3 — Match output 3 from Timer 2.
SCT0_OUT8 — SCTimer/PWM output 8.
TRACEDATA[2] — Trace data bit 2.
