Table 60. Revision history …continued
Document ID
LPC546xx v.1.5
Modifications:
Release date Data sheet status
20170331 Product data sheet
Change notice Supersedes
-
LPC546xx v.1.4
• Updated Table 51 “Dynamic characteristics: SD/MMC and SDIO”. The max clock
frequency is 50 MHz.
• Updated Section 7.18.2 “SD/MMC card interface”: Supports up to a maximum of 50
MHz of interface frequency.
• Updated Table 41 “Dynamic characteristic: I2C-bus pins[1]”
• Updated Figure 28 “I2S-bus timing (master)” and Figure 29 “I2S-bus timing (slave)”.
• Updated Table 2 “Ordering options”. Parts LPC54618J512ET180 and
LPC54618J512BD208 have Classic CAN.
• Added Section 11.4 “Wake-up process”.
LPC546xx v.1.4
Modifications:
20170307
Product data sheet
-
LPC5460x v.1.3
• Changed data sheet title to LPC546xx.
• Updated Table 16 “Static characteristics: Power consumption in deep-sleep and deep
power-down modes” and Table 17 “Static characteristics: Power consumption in
deep-sleep and deep power-down modes”.
LPC5460x v.1.3
Modifications:
20170224
Product data sheet
-
LPC5460x v.1.2
• Removed S parts. Data sheet title renamed to LPC5460x.
• Removed AES-256 engine and SHA references throughout the document.
• Security peripherals renamed to Security features.
• Updated Section 4 “Marking”.
• Updated Section 5 “Block diagram”.
• Updated Figure 6 “LPC546xx Memory mapping”.
• Updated Table 20 “Typical AHB/APB peripheral power consumption [3][4][5]”.
LPC5460x v.1.2
Modifications:
20170206
Product data sheet
-
LPC5460x v.1.1
• Updated address range details and description of the address range: 0x8000 0000 to
0xDFFF FFFF: See Table 7 “Memory usage and details”: Static memory chip select:
was 0x9000 0000 - 0x93 FFFF, now, 0x9000 0000 – 0x93FF FFFF.
• Updated Figure 8 “LPC5460x clock generation”.
• Updated Power control in Section 2 “Features and benefits”: Ultra-low power Micro-tick
Timer, running from the Watchdog oscillator that can be used to wake up the device
from low power modes.
• Updated Table 4 “Pin description”: PIO0_26, USB0_IDVALUE, Type is Input (I).
• Updated Section 7.18.1.1 “Features”.
• Updated Table 31 “Dynamic characteristics of the PLL0[1]”: Input frequency, Fin, Max
value is 25 MHZ.
LPC5460x v.1.1
20170124
Product data sheet
-
LPC5460x v.1
