LPC546xx
NXP Semiconductors
32-bit ARM Cortex-M4 microcontroller
13. Application information
13.1 Start-up behavior
Figure 43 shows the start-up timing after reset. The FRO 12 MHz oscillator provides the
default clock at Reset and provides a clean system clock shortly after the supply pins
reach operating voltage.
FRO
starts
FRO status
internal reset
V
DD
valid threshold
= 1.71 V
t
a
μs
t μs
b
GND
boot time
supply ramp-up
time
user code
t
c
μs
processor status
boot code
execution
finishes;
user code starts
aaa-024049
Fig 43. Start-up timing
Table 58. Typical start-up timing parameters
Parameter
Description
Value
ta
tb
tc
FRO start time
20 s
151 s
262 s
245 s
289 s
Internal reset de-asserted
Legacy image
Single image without CRC
Dual image without CRC
LPC546xx
