LPC546xx
NXP Semiconductors
32-bit ARM Cortex-M4 microcontroller
11.18 Smart card interface
Table 46. Dynamic characteristics[1]
Tamb = 40 C to 105 C; VDD = 1.71 V to 3.6 V; CL = 30 pF balanced loading on all pins; Input slew = 1 ns, SLEW setting =
standard mode for all pins; Parameters sampled at the 90 % and 10 % level of the rising or falling edge.
Symbol
Parameter
Conditions
Min
Typ
Max
Unit
2.7 V VDD 3.6 V
tDS
data set-up time
CCLK 100 MHz
2.1
-
-
-
-
-
-
-
ns
ns
ns
ns
ns
ns
100 MHz < CCLK 180 MHz 2.1
-
tDH
data hold time
CCLK 100 MHz
0
-
100 MHz < CCLK 180 MHz
0
-
tv(Q)
data output valid time CCLK 100 MHz
11.0
22.5
22.5
100 MHz < CCLK 180 MHz 11.0
[1] Based on simulated values. VDD = 2.7 V - 3.6 V.
LPC546xx
All information provided in this document is subject to legal disclaimers.
© NXP Semiconductors N.V. 2018. All rights reserved.
Product data sheet
Rev. 2.5 — 20 June 2018
129 of 169
