Series KP
Miniature Audio/Video Pushbuttons
PLUNGERS
B
9.2mm Plunger
A
11.6mm Plunger
for 15.0mm & 17.4mm Caps
(9.2)
.362
(11.6)
.457
for 12.0mm Cap
(6.4)
.252
(6.4)
.252
9.2mm Plunger is designed
11.6mm Plunger is designed
with a narrower neck to
hold the 12.0mm Cap.
with a wider neck to hold both
the 15.0mm and 17.4mm Caps.
CAP TYPES & COLORS
1
2
D
Used on A Plunger
12.0mm Square
S
T
F
AT3083 Flat Cap
AT3078 Sculptured Cap
AT3086 Home Key Cap
(6.5)
.256
(6.5)
.256
(6.5)
.256
(2.6) Dia
.102
(12.0) Sq
.472
(12.0) Sq
.472
(12.0) Sq
.472
Used on B Plunger
15.0mm Square
T
F
S
AT3079 Sculptured Cap
AT3087 Home Key Cap
AT3084 Flat Cap
(7.0)
.276
(7.0)
.276
(7.0)
.276
(2.6) Dia
.102
(15.0) Sq
.591
(15.0) Sq
.591
(15.0) Sq
.591
3
Used on B Plunger
17.4mm Square
T
F
S
AT3080 Sculptured Cap
AT3088 Home Key Cap
AT3085 Flat Cap
(7.0)
.276
(7.0)
.276
(7.0)
.276
(2.6) Dia
.102
(17.4) Sq
.685
(17.4) Sq
.685
(17.4) Sq
.685
JB
Lens & Diffuser Colors Available:
Clear Lens
Clear/White
White Diffuser
Materials & Finishes: Lens - Polycarbonate with glossy finish; Diffuser - Polycarbonate with textured finish
Optional Protective Guard AT4170 available; contact factory.
D40
