74VHC541; 74VHCT541
Nexperia
Octal buffer/line driver; 3-state
Table 7.
Dynamic characteristics …continued
GND = 0 V. For test circuit see Figure 7.
Symbol Parameter Conditions
25 °C
−40 °C to +85 °C −40 °C to +125 °C Unit
Min Typ[1] Max Min
Max
Min
Max
For type 74VHCT541
[2]
tpd
propagation An to Yn; see Figure 5
delay
VCC = 4.5 V to 5.5 V
CL = 15 pF
CL = 50 pF
-
-
3.5
5.0
5.5
8.5
1.0
1.0
6.5
9.5
1.0
1.0
7.0
ns
ns
11.0
ten
enable time OEn to Yn; see Figure 6
VCC = 4.5 V to 5.5 V
CL = 15 pF
-
-
4.0
7.0
1.0
1.0
8.0
1.0
1.0
9.0
ns
ns
CL = 50 pF
5.5 10.0
12.0
12.5
[2]
[3]
tdis
disable time OEn to Yn; see Figure 6
VCC = 4.5 V to 5.5 V
CL = 15 pF
-
-
-
5.0
7.0 10.0
12
7.0
1.0
1.0
-
8.0
12.0
-
1.0
1.0
-
9.0
12.5
-
ns
ns
pF
CL = 50 pF
CPD
power
per buffer;
-
dissipation
CL = 50 pF; f = 1 MHz;
capacitance VI = GND to VCC
[1] Typical values are measured at nominal supply voltage (VCC = 3.3 V and VCC = 5.0 V).
[2] tpd is the same as tPLH and tPHL
ten is the same as tPZL and tPZH
tdis is the same as tPLZ and tPHZ
.
.
.
[3] CPD is used to determine the dynamic power dissipation PD (µW).
PD = CPD × VCC2 × fi + ∑(CL × VCC2 × fo) where:
fi = input frequency in MHz;
fo = output frequency in MHz;
CL = output load capacitance in pF;
VCC = supply voltage in Volts.
©
