CHAPTER 12 SERIAL INTERFACE 20
(c) Asynchronous serial interface status register 20 (ASIS20)
ASIS20 is set with a 1-bit or 8-bit memory manipulation instruction.
RESET input sets ASIS20 to 00H.
Symbol
ASIS20
7
0
6
0
5
0
4
0
3
0
<2>
<1>
<0>
Address
FF71H
After reset
00H
R/W
R
PE20
FE20
OVE20
PE20
Parity error flag
0
1
No parity error has occured
A parity error has occured (when the parity of transmit data does not match)
Framing error flag
FE20
0
1
No framing error has occured
A framing error has occured (when stop bit is not detected)Note 1
OVE20
Overrun error flag
No overrun error has occured
0
1
An overrun error has occuredNote 2
(when the next receive operation is completed before data is read from reception buffer register 20)
Notes 1. Even when the stop bit length is set to 2 bits by setting bit 2 (SL20) of asynchronous serial
interface mode register 20 (ASIM20), the stop bit detection at reception is performed with 1
bit.
2. Be sure to read reception buffer register 20 (RXB20) when an overrun error occurs. If not,
every time the data is received an overrun error will occur.
User’s Manual U15075EJ1V0UM00
227
