SPECIFICATIONS
at 25˚C (77˚F)
Item s
5 A Type
10/15 A Type
Contact Form
1 form C
Contact Material
Silver nickel alloy
Silver oxide com plex alloy
Contact Resistance
Contact Switching Voltage
Contact Switching Current
Contact Carrying Current
Operate Tim e
100 m Ω m ax. (m easured at 0.5 A) initial
30 Vdc m ax. 5 Vdc m in.
100 m Ω m ax. (m easured at 2 A) initial
5 A m ax. (at 16 Vdc) 0.1 A m in.
20 A m ax. (at 12 Vdc)
15/20 A m ax. (at 16 vdc) 1 A m in.
Approx. 5 m s m ax. (at I 2 Vdc, excluding bounce) initial
Approx. 2 m s m ax. (at I 2 Vdc, excluding bounce) initial, without diode
0.36 W/0.45 W (Nom inal Voltage)
Release Tim e
Nom inal Operate Power
Insulation Resistance
Breakdown Voltage
Shock Resistance
100 MΩ m in. (at 500 Vdc) initial
500 Vdc m in. (for 1 m inute) initial
98 m /s2 [Approx. 10 G] m in. (m isoperating)
10 to 300 Hz, 43 m /s2 [Approx. 4.4 G] m in. (m isoperating)
–40˚C to +85˚C (–40˚F to +185˚F)
Vibration Resistance
Am bient Tem perature
Coil Tem perature Rise
50˚C/W (contact carrying current 0 A)
1 x 106 operations
Mechanical
Electrical
Life Expectancy
Weight
1 x 105 operations (at 14 Vdc, Motor Load 20 A/3 A) (E-Contact)
Approx. 13 gr
9
