Dimensions（Common to ASB, ASL and AHB Series）
●Female thread type
TOP VIEW
17
Enlarged of section A
Model
L（mm）
P type
D type
ASB170C801NP0LF
ASL170C801NP0LF
ASB340C801NP0LF
ASL340C801NP0LF
ASB510C801NP0LF
ASL510C801NP0LF
ASB680C801NP0LF
ASL680C801NP0LF
38.4
φ2.2
58.4
78.4
98.4
φ11.5±0.5
Section A
90°
L±0.5
Model
L（mm）
58.4
2.5±0.2
130±10
AHB550C801NP0LF
AHB700C801NP0LF
AHB800C801NP0LF
2
78.4
19±0.5
9±0.2
78.4
[mm]
＊Both P type and D type have the same
overall lengths
φ19.6±0.5
17
＊Lead wire: AWG26, UL1371
Red color:（＋）
White color:（－）
M4 screw of min. 3 deep
Prepared hole of max. 5 deep
BOTTOM VIEW
●Flange type
Enlarged of section A
P type
TOP VIEW
Model
L（mm）
17
ASB170C801FP0LF
ASL170C801FP0LF
ASB340C801FP0LF
ASL340C801FP0LF
ASB510C801FP0LF
ASL510C801FP0LF
ASB680C801FP0LF
ASL680C801FP0LF
32.4
φ2.2
52.4
72.4
92.4
D type
4－
φ
3.5
φ11.5±0.5
Section A
t
n
e
90°
m
e
c
a
l
p
s
i
d
f
o
n
o
Model
L（mm）
52.4
i
t
L±0.5
c
e
r
i
AHB550C801FP0LF
AHB700C801FP0LF
AHB800C801FP0LF
D
130±10
2.5±0.2
3.0±0.2
72.4
2
72.4
[mm]
13.0±0.5
＊Both P type and D type have the same
overall lengths
P.C.D.28
45°
45°
＊Lead wire: AWG26, UL1371
Red color:（＋）
White color（: －）
φ35±0.5
BOTTOM VIEW
