Performance
Item
Standard
Conditions
When applied with DC voltage: Ambient temperature
When driven by pulse: Ambient temperature + Temperature rise due
to generated heat
ASB/AHB : ー25 to ＋85℃
ASL : ー40 to ＋150℃
Operating temperature range
Recommended Storage
condition
ー5 to ＋40℃
Maximum driving voltage
Displacement
150VDC
See the standard parts list
At 150VDC
The force required for restricting the displacement to 0 when the
maximum driving voltage is applied.
Generated force
（compression resistance）
See the standard parts list
Capacitance
See the standard parts list
＋/ー20%
Capacitance tolerance
Dissipation factor
Insulation resistance
f＝1kHz, V＝1Vrms
5% or less
See the standard parts list
Value obtained in 1 minute at 150 VDC
With both ends of element in free state
Resonance frequency
Airtightness
See the standard parts list
Typical value of the element under our test conditions
1×10ー8 atm cc/sec or less
ASB, AHB
Room temperature（3 min） Room temperature（3 min）
－25℃（30 min） －40℃（30 min）
Room temperature（3 min） Room temperature（3 min）
＋85℃（30 min） ＋150℃（30 min）
ASL
Displacement: Initial value ±30%
Capacitance: Initial value ±30%
tanδ: Less than initial rated value
Insulation resistance: 1 MΩ or more
Appearance: No noticeable defect
Temperature cycle test
High-temperature shelf test
Solvent resistance test
Repetition of 10 cycles of the above
Displacement: Initial value ±30%
Capacitance: Initial value ±30%
tanδ: Less than initial rated value
Insulation resistance: 1 MΩ or more
Appearance: No noticeable defect
Temperature ASB, AHB: 85±2℃
ASL: 150±2℃
Time
1,000±48 h
Displacement: Initial value ±30%
Capacitance: Initial value ±30%
tanδ: Less than initial rated value
Insulation resistance: 1 MΩ or more
Appearance: No noticeable defect
Mark: Easily legible
Solvent: Isopropyl alcohol
Temperature: 23±5℃
Time: Immersion for 1 min
Displacement: Initial value ±30%
Capacitance: Initial value ±30%
tanδ: Less than initial rated value
Insulation resistance: 1 MΩ or more
Appearance: No noticeable defect
Mark: Easily legible
Temperature: 150±3℃
Time: 96±4 h
Heat resistance test
Multilayer Piezoelectric Actuators Vol.06 13
