DDR3(L)-2Gb SDRAM
NT5CB(C)256M8JQ/NT5CB(C)128M16JR
Read Timing; Clock to Data Strobe relationship
Clock to Data Strobe relationship is shown in the following figure and is applied when the DLL is enabled and locked.
Rising data strobe edge parameters:
• tDQSCK min/max describes the allowed range for a rising data strobe edge relative to CK and .
• tDQSCK is the actual position of a rising strobe edge relative to CK and .
• tQSH describes the data strobe high pulse width.
Falling data strobe edge parameters:
• tQSL describes the data strobe low pulse width.
Clock to Data Strobe Relationship
RL Measured
to this point
CK
CK
tLZ(DQS)min
tDQSCKmin
tHZ(DQS)min
tRPRE
tQSH tQSL
tRPST
DQS, DQS
Early Strobe
tHZ(DQS)max
tDQSCKmax
tRPST
tLZ(DQS)max
DQS, DQS
Late Strobe
tRPRE
NOTES:
1. Within a burst, rising strobe edge is not necessarily fixed to be always at tDQSCK(min) or tDQSCK(max). Instead, rising strobe edge
can vary between tDQSCK(min) and tDQSCK(max).
2. The DQS, differential output high time is defined by tQSH and the DQS, differential output low time is defined by tQSL.
3. Likewise, tLZ(DQS)min and tHZ(DQS)min are not tied to tDQSCKmin (early strobe case) and tLZ(DQS)max and tHZ(DQS)max are not
tied to tDQSCKmax (late strobe case).
4. The minimum pulse width of read preamble is defined by tRPRE(min).
5. The maximum read postamble is bound by tDQSCK(min) plus tQSH(min) on the left side and tHZDSQ(max) on the right side.
6. The minimum pulse width of read postamble is defined by tRPST(min).
7. The maximum read preamble is bound by tLZDQS(min) on the left side and tDQSCK(max) on the right side.
