DDR3(L)-2Gb SDRAM
NT5CB(C)256M8JQ/NT5CB(C)128M16JR
NANYA Component Part Numbering Guide
NT
5C
B
H
Grade
H = Automotive Grade 2
A = Automotive Grade 3
NANYA
Technology
Product Family
5C = DDR3 SDRAM
Speed
Interface & Power(VDD&VDDQ)
B= SSTL_15 (1.5V,1.5V)
C= SSTL_135 (1.35V,1.35V)
FL = 2133-14-14-14
EK = 1866-13-13-13
DI = 1600-11-11-11
Organization (Depth, Width)
M=Mono
2Gb = 256M8 = 128M16
Package Code
HSF + Halogens-Free
Height=1.1+/-0.1 mm
Q = DDR3 78-Ball TFBGA
R = DDR3 96-Ball TFBGA
Device Version
J = 10th version
Operating frequency
Please confirm with NTC when the operating frequency is slower than the defined frequency in the following table.
Frequency[MHz]
CL[nCK]
1066
14
933
13
800
11
Unit
VDD[V]
1.5
1.35
1.5
1.35
1.5
NT5CB256M8JQ-FLH(A)
NT5CB128M16JR-FLH(A)
NT5CC256M8JQ-EKH(A)
NT5CC128M16JR-EKH(A)
NT5CB256M8JQ-EKH(A)
NT5CB128M16JR-EKH(A)
NT5CC256M8JQ-DIH(A)
NT5CC128M16JR-DIH(A)
NT5CB256M8JQ-DIH(A)
NT5CB128M16JR-DIH(A)
2133
N/A
1866
1866
N/A
Mbps
Mbps
Mbps
Mbps
Mbps
1600
1600
1600
N/A
N/A
1866
N/A
N/A
N/A
N/A
N/A
1600
Notes:
Any part number also supports functional operation at lower frequencies as shown in the table which are not subject to Production Tests
but has been verified.
Version 1.4
05/2019
