LLL/LLA/LLM Series Specifications and Test Methods (2)
In case Non "*" is added in PNs table, please refer to LLL/LLA/LLM Series Specifications and Test Methods (1).
Continued from the preceding page.
In case "*" is added in PNs table, please refer to LLL/LLA/LLM Series Specifications and Test Methods (2).
No.
Item
Appearance No marking defects
Specifications
Test Method
Fix the capacitor to the supporting jig in the same manner and
under the same conditions as (10).Perform the five cycles
according to the four heat treatments listed in the following
table. Let sit for 24±2 hours at room temperature,
then measure.
Capacitance
Change
R6, R7, C7, C8: Within ±12.5%
3
D.F.
R6, R7, C7, C8: 0.120 max.
Temperature I.R.
50Ω · F min.
Step
1
2
3
4
14 Sudden
Change
Min. Operating Room Min. Operating Room
Temp. (°C)
Time (min.)
+0
–3
+0
–3
Temp.
Temp.
Temp.
Temp.
30±3
2 to 3
30±3
2 to 3
Dielectric
Strength
No failure
• Initial measurement
Perform a heat treatment at 150
+0
–
10
°C for one hour and then
let sit for 24±2 hours at room temperature. Perform the initial
measurement.
Appearance No marking defects
Apply the rated voltage at 40±2°C and 90 to 95% humidity for
500±12 hours.
The charge/discharge current is less than 50mA.
Apply the rated DC voltage.
Capacitance
R6, R7, C7, C8: Within ±12.5%
Change
High
Temperature
D.F.
R6, R7, C7, C8: 0.2 max.
•Initial measurement
+0
High
15
Perform a heat treatment at 150
–
10
°C for one hour and then
Humidity
(Steady
State)
let sit for 24±2 hours at room temperature. Perform the initial
measurement.
I.R.
12.5Ω · F min.
•Measurement after test
+0
Perform a heat treatment at 150
–
10
°C for one hour and then
let sit for 24±2 hours at room temperature, then measure.
Appearance No marking defects
Apply 150% of the rated voltage for 1000±12 hours at the
maximum operating temperature ±3°C.
The charge/discharge current is less than 50mA.
Capacitance R6, R7, C7, C8: Within ±12.5%
Change
* LLL153C70G474: Within ±20%
D.F.
R6, R7, C7, C8: 0.2 max.
•Initial measurement
+0
Perform a heat treatment at 150
–
10
°C for one hour and then
let sit for 24±2 hours at room temperature. Perform the initial
16 Durability
measurement.
I.R.
25Ω · F min.
•Measurement after test
+0
Perform a heat treatment at 150
–
10
°C for one hour and then
let sit for 24±2 hours at room temperature, then measure.
