Eight Terminals Low ESL Type X7R(R7)/X7S(C7) Characteristics Low Profile
LxW [mm]
2.0x1.25(21)<0805>
Rated Volt. [Vdc]
Capacitance
10000pF(103)
22000pF(223)
47000pF(473)
0.10µF(104)
0.22µF(224)
0.47µF(474)
25(1E)
16(1C)
10(1A)
6.3(0J)
Tolerance
±20% (M)
±20% (M)
±20% (M)
±20% (M)
±20% (M)
±20% (M)
Part Number
LLA215R71E103MA14L
LLA215R71E223MA14L
3
LLA215R71C473MA14L
LLA215R71C104MA14L
LLA215R71A224MA14L
LLA215R70J474MA14L
LxW [mm]
2.0x1.25(21)<0805>
4(0G)
Rated Volt. [Vdc]
Capacitance
1.0µF(105)
Tolerance
±20% (M)
±20% (M)
±20% (M)
Part Number
LLA215C70G105MA14L
LLA215C70G225ME11L*
LLA215C70G475ME19L*
2.2µF(225)
4.7µF(475)
LxW [mm]
3.2x1.6(31)<1206>
10(1A)
Rated Volt. [Vdc]
Capacitance
0.22µF(224)
0.47µF(474)
1.0µF(105)
16(1C)
6.3(0J)
Tolerance
±20% (M)
±20% (M)
±20% (M)
±20% (M)
Part Number
LLA315R71C224MA14L
LLA315R71A474MA14L
LLA315R70J105MA14L
LLA315R70J225MA14L
2.2µF(225)
The part number code is shown in ( ) and Unit is shown in [ ].
< >: EIA [inch] Code
*: Please refer to LLL/LLA/LLM Series Specifications and Test Method(2).
Ten Terminals Low ESL Type X7R(R7)/X7S(C7) Characteristics Low Profile
LxW [mm]
2.0x1.25(21)<0805>
Rated Volt. [Vdc]
Capacitance
10000pF(103)
22000pF(223)
47000pF(473)
0.10µF(104)
0.22µF(224)
0.47µF(474)
1.0µF(105)
25(1E)
16(1C)
6.3(0J)
4(0G)
Tolerance
±20% (M)
±20% (M)
±20% (M)
±20% (M)
±20% (M)
±20% (M)
±20% (M)
±20% (M)
Part Number
LLM215R71E103MA11L
LLM215R71E223MA11L
LLM215R71C473MA11L
LLM215R71C104MA11L
LLM215R70J224MA11L
LLM215R70J474MA11L
LLM215C70G105MA11L
LLM215C70G225ME11L*
2.2µF(225)
LxW [mm]
3.2x1.6(31)<1206>
10(1A)
Rated Volt. [Vdc]
Capacitance
0.10µF(104)
0.22µF(224)
0.47µF(474)
2.2µF(225)
16(1C)
6.3(0J)
Tolerance
±20% (M)
±20% (M)
±20% (M)
±20% (M)
Part Number
LLM315R71C104MA11L
LLM315R71C224MA11L
LLM315R71A474MA11L
LLM315R70J225MA11L
The part number code is shown in ( ) and Unit is shown in [ ].
< >: EIA [inch] Code
*: Please refer to LLL/LLA/LLM Series Specifications and Test Method(2).
qProduct ID
tTemperature Characteristics
iCapacitance Tolerance
wSeries
eDimension (LxW)
yRated Voltage
oIndividual Specification Code !Packaging
rDimension (T)
uCapacitance
(Part Number) LL
A
21
5
R7 1E 103
M
A14
L
q
w
e
r
t
y
u
i
o
!
Packaging Code in Part Number is a code shows STD 180mm Reel Taping.
